These cables are intended for remote control and instrumentation where required no anti-inductive screen (for example where there is no capacitive interaction).
NYY-R, with its stranded conductor, is intended more particularly for installations subject to vibration.
Construction:
Conductor: solid copper / stranded copper
Insulation : PVC
Filler : PVC (or ruban d’assemblage)
Sheath : PVC Grey
These cables are intended for remote control and instrumentation where required no anti-inductive screen (for example where there is no capacitive interaction).
NYY-R, with its stranded conductor, is intended more particularly for installations subject to vibration.
Construction :
Conductor: solid copper / stranded copper
Insulation : PVC
Filler : PVC (or Assembly tape)
Sheath : PVC Grey
Characteristics :
Rated voltage : 0,6/1 kV
Conductor :
NYY-M Solid copper class 1
NYY-R Stranded copper class 2
Maximum permissible temperature : 70° C continuous/ 160° C short circuit
Conductor identification : Conductor black marqués en chiffres white 1,2,..., n-1 with a G/Y conductor last
